Simpson Strong-Tie TNTB25314TTRB Titen Turbo (1/4" x 3-1/4") T25 Trim-Head Screw Anchor, Bronze (1000 Pack)
Couldn't load pickup availability
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
Simpson Strong-Tie TNTB25314TTRB Titen Turbo (1/4" x 3-1/4&quo...
Key Specifications
Description
Description
Simpson Strong-Tie TNTB25314TTRB Description
The Simpson Strong-Tie Titen Turbo screw anchor is a heavy-duty fastener designed for quick and easy installation in wood-to-concrete and wood-to-wood anchoring applications.
Simpson Strong-Tie TNTB25314TTRB Includes
- (1000) Titen Turbo Screw Anchor Bronze Zinc 1/4" x 3-1/4"
- (2) T25 drive bits
Simpson Strong-Tie TNTB25314TTRB Features
- Patented Torque Reduction Channel for reduced binding
- Available in multiple coated versions including Bronze Zinc
- 6-lobe drive for positive bit engagement
- Superior tension load performance
- Designed for use with impact drivers or cordless drills
Simpson Strong-Tie TNTB25314TTRB Applications
- Electrical boxes and conduit mounting
- Switch boxes and light fixtures installation
- Window and threshold anchoring
- Basement furring strips attachment
- Shelf mounting to concrete or CMU
- Handrails installation
Simpson Strong-Tie TNTB25314TTRB Installation Overview
- Drill a hole in the base material using a 3/16" carbide drill bit to the specified depth.
- Position the fixture and insert the screw.
- Tighten using a drill and the Titen Turbo installation tool fitted with a hex socket or 6-lobe bit socket.
Simpson Strong-Tie TNTB25314TTRB Specifications
| Material | Carbon Steel |
| Finish | Zinc plated with a baked-on ceramic coating |
| Diameter | 1/4" |
| Length | 3-1/4" |
| Drill Bit Diameter | 3/16" |
| Drive Type | T25 6-Lobe |
| Head Type | Trim Head |
| Color | Bronze |
| Packaging Quantity | 1000 |
NOTE: Designed for installation with an impact driver or cordless drill. Installation using the Titen Turbo Installation Tool is recommended. Matched-tolerance bit not required; use a standard ANSI drill bit for installation. Intended for use in dry interior environments only.
