Simpson Strong-Tie ECC96 End Column Cap for 9x Beam to 6x Post Connection, Gray Paint
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
Simpson Strong-Tie ECC96 End Column Cap for 9x Beam to 6x Post Conn...
Key Specifications
Description
Description
Simpson Strong-Tie ECC96 Description
The Simpson ECC96 End Column Cap enhances the strength and stability of your construction projects, providing a durable and reliable column-to-beam connection.
Simpson Strong-Tie ECC96 Includes
- (4) 3/4" Machine Bolts for Beam
- (2) 3/4" Machine Bolts for Post
Simpson Strong-Tie ECC96 Features
- Provides strong end-of-beam connection for column-to-beams
- Extended area of the column seat offers additional surface area of bearing to distribute the load
- Made from Steel for durability and finished with Gray Paint coating
- Certified welds for strength and loading with increased uplift loads for earthquake or wind loading
- Features diamond holes to provide temporary fastening during installation, bolt spacing to meet NDS code requirements
Simpson Strong-Tie ECC96 Applications
- Column-to-beam connections in end-of-beam applications for wood construction
- Suitable for use with 6x posts or columns and 9x beams
Simpson Strong-Tie ECC96 Specifications
| Finish | Gray Paint |
| Material | Steel |
| Beam size | 9x |
| Fasteners required | Beam - (4) 3/4" Machine Bolts, Post - (2) 3/4" Machine Bolts |
| For Treated Lumber | No |
| Post size | 6x |
| Thickness | 3 Gauge |
NOTE: This item is made to order and is non-returnable.
WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov
