Simpson Strong-Tie STB2-62500 Strong-Bolt 2 (5/8" x 5") Stainless Steel Wedge Anchor - Fully Assembled (20 Pack)
Couldn't load pickup availability
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
Simpson Strong-Tie STB2-62500 Strong-Bolt 2 (5/8" x 5") S...
Key Specifications
Description
Description
Simpson STB2-62500 Description
The Strong-Bolt 2 Wedge Anchor is a high-performance anchor designed for cracked and uncracked concrete applications, featuring a mechanically galvanized finish for durability.
Simpson STB2-62500 Includes
- (20) 5/8 in. x 5 in. Mechanically Galvanized Wedge Anchor
Simpson STB2-62500 Features
- Chamfered top prevents mushrooming during installation
- Qualified for static and seismic loading conditions
- Suitable for horizontal, vertical, and overhead applications
- Mechanically galvanized for corrosion resistance
- Tested per ACI355.2 and AC193 standards
Simpson STB2-62500 Applications
- Concrete anchoring in cracked and uncracked conditions
- Seismic and static load applications
- Horizontal, vertical, and overhead installations
Simpson STB2-62500 Installation Overview
- Drill a hole using a carbide drill bit matching the anchor diameter
- Clean the hole using compressed air
- Insert the anchor with nut and washer assembled
- Drive the anchor until the washer and nut are tight against the fixture
- Tighten to the specified installation torque
Simpson STB2-62500 Specifications
| Diameter | 5/8 in. |
| Length | 5 in. |
| Finish | Mechanically Galvanized |
| Material | Carbon Steel |
| Drill Bit Size | 5/8 in. |
| Fixture Hole Size | 11/16 in. |
| Installation Torque | 60 ft. lbf. |
| Thread Length | 2-15/16 in. |
NOTE: Ensure proper installation torque and avoid oversized holes to maintain load capacity
