Simpson Strong-Tie BC4Z (4x) 18 Gauge Post Cap - ZMAX Finish
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
Simpson Strong-Tie BC4Z (4x) 18 Gauge Post Cap - ZMAX Finish
Key Specifications
Description
Description
Simpson BC4Z Description
The Simpson BC4Z Post Cap ZMAX enhances the strength and stability of construction projects, securely connecting beams to posts with durable 18-gauge steel and ZMAX coating.
Simpson BC4Z Includes
- (1) Post Cap ZMAX for 4x Nominal Lumber
Simpson BC4Z Features
- Designed to connect beams to posts
- Provides uplift and lateral resistance
- Made from durable 18-gauge steel
- Finished with ZMAX coating for corrosion resistance
- Attains full allowable load using common or pneumatic nails
Simpson BC4Z Applications
- Beam-to-post connections in construction
- Light-duty connections for 4x posts
- Structural support for nominal and rough-cut lumber
Simpson BC4Z Installation Overview
- Position the post cap on the beam and post as per the design.
- Secure the beam flange using (6) 0.162 x 3-1/2" nails.
- Secure the post flange using (6) 0.162 x 3-1/2" nails.
- Verify the installation for proper alignment and fastening.
Simpson BC4Z Specifications
| Finish | ZMAX |
| Length | 2-7/8" |
| Material | 18-Gauge Steel |
| Fasteners required | Beam Flange - (6) 0.162 x 3-1/2" nails; Post Flange - (6) 0.162 x 3-1/2" nails |
| Height | 3" |
| Post size | 4x |
| Quantity | 1 |
| Thickness | 18 Gauge |
| Width | 3-9/16" |
NOTE: Ensure the correct fasteners are installed in the correct position to achieve published load values
WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov
