Simpson BPS 3/4-6 Slotted Bearing Plate with 3/4" Bolt Diameter
Couldn't load pickup availability
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
Simpson BPS 3/4-6 Slotted Bearing Plate with 3/4" Bolt Diameter
Key Specifications
Description
Description
Simpson Strong-Tie BPS 3/4-6 Description
The Simpson Strong-Tie BPS 3/4-6 Slotted Bearing Plate is designed for wood-to-concrete applications, offering adjustability and high load support.
Simpson Strong-Tie BPS 3/4-6 Includes
- (1) Slotted Bearing Plate
Simpson Strong-Tie BPS 3/4-6 Features
- Eliminates the need for standard-cut washers when used with Titen HD heavy-duty screw anchors
- Slotted hole allows for adjustability
- Available with a hot-dip galvanized finish for higher corrosion resistance
- Heavy-duty construction from 3 Gauge steel
- Compact size of 4.5" x 3"
Simpson Strong-Tie BPS 3/4-6 Applications
- Wood-to-concrete fastening
- Structural reinforcement in construction projects
- Heavy-duty framing and load-bearing applications
Simpson Strong-Tie BPS 3/4-6 Installation Overview
- Position the edge of the plate washer within 1/2" of the sheathed edge of the sill plate for shearwall applications.
- Tighten the plate to each anchor bolt with a nut and standard cut-washer.
- Ensure proper alignment and secure fastening.
Simpson Strong-Tie BPS 3/4-6 Specifications
| Material | 3 Gauge Steel |
| Finish | Plain or Hot-Dip Galvanized |
| Bolt Diameter | 3/4" |
| Dimensions | 4.5" x 3" |
| Weight | 0.9 lb |
NOTE: Standard cut-washer required with BPS slotted bearing plates. Washer not required when used with Titen HD heavy-duty screw anchors.
