Simpson BPS 3/4-6HDG Strong-Tie Slotted Bearing Plate with 3/4" Bolt Dia.
Couldn't load pickup availability
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
Simpson BPS 3/4-6HDG Strong-Tie Slotted Bearing Plate with 3/4"...
Key Specifications
Description
Description
Simpson Strong-Tie BPS 3/4-6HDG Description
The Simpson Strong-Tie BPS 3/4-6HDG is a slotted bearing plate designed for wood-to-concrete fastening applications, featuring a 3/4" bolt diameter and hot-dip galvanized finish for enhanced corrosion resistance.
Simpson Strong-Tie BPS 3/4-6HDG Includes
- (1) Slotted Bearing Plate
Simpson Strong-Tie BPS 3/4-6HDG Features
- Eliminates the need for standard-cut washers when used with Titen HD heavy-duty screw anchors
- Slotted hole allows for adjustability
- Hot-dip galvanized finish for higher corrosion resistance
Simpson Strong-Tie BPS 3/4-6HDG Applications
- Wood-to-concrete fastening
- Masonry anchoring
Simpson Strong-Tie BPS 3/4-6HDG Installation Overview
- Position edge of plate washer within 1/2" of sheathed edge of sill plate for shearwall applications
- Use standard cut-washer with BPS slotted bearing plates unless used with Titen HD heavy-duty screw anchors
- Tighten BPS to each anchor bolt with nut and standard cut-washer
Simpson Strong-Tie BPS 3/4-6HDG Specifications
| Bolt Diameter | 3/4" |
| Gauge | 3 |
| Thickness | 0.229" |
| Width | 3" |
| Length | 4 1/2" |
| Finish | Hot-Dip Galvanized |
NOTE: Standard cut-washer required with BPS 1/2-3, BPS 5/8-3, BPS 3/4-3, BPS 1/2-6, BPS 5/8-6, and BPS 3/4-6 (not provided) per the 2012/2015/2018/2021 IRC and 2015/2021 SDPWS.
